NSK 7016C Angular Contact Ball Bearing
I.NSK bearings, material of pure, high precision products, more than hundreds of thousands of varieties, widely used in different environments and machinery.Angular contact ball bearings are used for combination radial and axial loading,they have raceways in the inner and outer rings that are displaced with respect to each other in the direction of the bearing axis.
II. The Main Parameter of NSK 7016C Angular Contact Ball Bearing :
Brand : NSK
Original : Japan
Type : Angular Contact Ball Bearing
Item: 7016C
Inner : 80 mm
Outner : 125 mm
Thickness : 22 mm
III. The similar type of NSK 7016C Angular Contact Ball Bearing :
| Part No. | d | D | T | W |
| (mm) | (mm) | (mm) | (kg) | |
| 7000C | 10 | 26 | 8 | 0.021 |
| 7000AC | 10 | 26 | 8 | 0.021 |
| 7001C | 12 | 28 | 8 | 0.024 |
| 7001AC | 12 | 28 | 8 | 0.024 |
| 7002C | 15 | 32 | 9 | 0.035 |
| 7002AC | 15 | 32 | 9 | 0.035 |
| 7003C | 17 | 35 | 10 | 0.045 |
| 7003AC | 17 | 35 | 10 | 0.045 |
| 7004C | 20 | 42 | 12 | 0.079 |
| 7004AC | 20 | 42 | 12 | 0.079 |
| 7005C | 25 | 47 | 12 | 0.091 |
| 7005AC | 25 | 47 | 12 | 0.091 |
| 7006C | 30 | 55 | 13 | 0.133 |
| 7006AC | 30 | 55 | 13 | 0.133 |
| 7007C | 35 | 62 | 14 | 0.17 |
| 7007AC | 35 | 62 | 14 | 0.17 |
| 7008C | 40 | 68 | 15 | 0.21 |
| 7008AC | 40 | 68 | 15 | 0.21 |
| 7009C | 45 | 75 | 16 | 0.26 |
| 7009AC | 45 | 75 | 16 | 0.26 |
| 7010C | 50 | 80 | 16 | 0.29 |
| 7010AC | 50 | 80 | 16 | 0.29 |
| 7011C | 55 | 90 | 18 | 0.42 |
| 7011AC | 55 | 90 | 18 | 0.42 |
| 7012C | 60 | 95 | 18 | 0.45 |
| 7012AC | 60 | 95 | 18 | 0.45 |
| 7013C | 65 | 100 | 18 | 0.47 |
| 7013AC | 65 | 100 | 18 | 0.47 |
| 7014C | 70 | 110 | 20 | 0.66 |
| 7014AC | 70 | 110 | 20 | 0.66 |
| 7015C | 75 | 115 | 20 | 0.69 |
| 7015AC | 75 | 115 | 20 | 0.69 |
| 7016C | 80 | 125 | 22 | 0.93 |
| 7016AC | 80 | 125 | 22 | 0.93 |
| 7017C | 85 | 130 | 22 | 0.97 |
IV. Our Advantages of NSK 7016C Angular Contact Ball Bearing :
1.Good Quality 2.Reasonable Price
3. Timely Delivery 4. Exquisite Packaging
